Copper-colored Rain Bird XFD dripline 100 ft coil, showing inline pressure-compensating emitters spaced 12 inches on flexible polyethylene tubing.

Rain Bird XFD Dripline - 0.6 GPH, 12 in Spacing, 100 ft

Brand: Rain Bird
Save 28%
$62.69
$45.45
SKU XFD0612100
In Stock (5)

Notify me when back in stock

Rain Bird XFD dripline delivers reliable, low-volume irrigation for landscape beds, containers, and foundation plantings. This copper-colored, flexible polyethylene tubing includes factory-installed, pressure-compensating inline emitters to maintain uniform flow across the lateral.

  • Flow rate: 0.6 GPH (2.3 l/h) per emitter with 12 in (30.5 cm) emitter spacing for consistent root-zone watering.
  • Length and size: 100 ft (30.5 m) coil; outer diameter 0.634 in (16.1 mm), inner diameter 0.536 in (13.6 mm), wall thickness 0.049 in (1.2 mm).
  • Operating range: Suitable for 8.5–60 psi; water up to 100°F and ambient up to 125°F. Requires 120-mesh filtration.
  • Durability: Dual-layer construction and copper-colored outer layer blend with mulch while resisting UV, algae, and common chemicals.
  • Compatibility: Use with Rain Bird XF insert fittings, 17 mm barb insert fittings, or Easy Fit compression fittings for straightforward installation.
  • Applications: Ideal for on-surface and shallow subsurface installations; extra-flexible tubing allows tight curves and reduces elbow fittings.

Choose Rain Bird XFD 0.6 GPH dripline when you need a flexible, pressure-compensating solution that simplifies installation and improves watering uniformity. Follow manufacturer guidelines for filtration and operating pressure to ensure long-term performance and clog resistance.

Reviews

Frequently Asked Questions

What is the emitter flow rate and spacing?
Each inline emitter delivers 0.6 GPH and is spaced 12 inches for consistent root-zone watering.
What filtration and pressure does this dripline require?
Requires 120-mesh filtration and operates well between 8.5 and 60 psi; follow system recommendations.
Can I use this tubing underground or on the surface?
Yes. XFD is suitable for on-surface and shallow subsurface installations and works well under mulch.
What fittings are compatible with Rain Bird XFD tubing?
Use Rain Bird XF insert fittings, 17 mm barb insert fittings, or Easy Fit compression fittings for secure connections.
