FEBCO 825Y reduced pressure zone backflow assembly, bronze body, 3/4" and 1" models, quarter-turn shutoffs and flood sensor.

FEBCO 825Y Reduced Pressure Zone Assembly (3/4" & 1")

Brand: Febco
Save 25%
$496.02
$372.02
SKU 905-045

Notify me when back in stock

The FEBCO 825Y Reduced Pressure Zone (RPZ) Assembly provides mechanical protection of potable water against high-hazard cross-connection contamination. Designed for commercial, industrial and irrigation applications, the 825Y includes a modular relief valve with flood sensor for early leak detection.

  • Bronze body with nitrile seats; sizes available include 3/4" and 1".
  • Includes quarter-turn ball shutoff valves, test cocks and modular relief valve for easy inline servicing.
  • Flood sensor compatible with SentryPlus Alert® system; optional connection kits available for BMS or cellular alerts.
  • Rated working pressure 175 psi (12.1 bar); hydrostatic test to 350 psi (24.1 bar).
  • Temperature range 32°F to 140°F (0°C to 60°C); weights: approx. 11.5 lb (3/4") and 12.5 lb (1").
  • Certified to ASSE 1013, AWWA C-511 and CSA B64.4; approved by USC Foundation for Cross-Connection Control and Hydraulic Research.

Installation, specification and maintenance literature are available with the product. All internal parts are serviceable in-line and replaceable seat rings simplify repairs. See the included documents for installation instructions, specification sheet, and freeze-protection guidance.

Reviews

Frequently Asked Questions

What sizes are available for the FEBCO 825Y assembly?
This listing covers 3/4" and 1" FEBCO 825Y models. The series is offered in larger sizes; see the specification sheet for full size range.
What are the pressure and temperature ratings?
Working pressure is 175 psi with hydrostatic test to 350 psi. Operating temperature range is 32°F to 140°F.
How serviceable are the internal parts and relief valve?
All internal parts are serviceable in-line; seat rings are replaceable and the modular relief valve simplifies repairs. Refer to the maintenance manual for procedures.
