Hunter PGJ Rotors

All the features and benefits of the PGP scaled down to fit typical spray applications.
A rack of easy-to-install-and-change, water-efficient nozzles just like PGP. The adjustable top of the sprinkler just like PGP. The safety and durability of a rubber cover very similar to PGP. The Hunter PGJ is a chip off the ol' block, in essence, a PGP junior." Hunter has scaled down the world's top-selling sprinkler exclusively for use in applications that typically call for a spray but where it's now possible to have all the benefits of a rotor. The PGJ is capable of working in tandem with larger rotors to combine big and small areas in a single zone, offering the convenience and efficiency that sprays do not. With PGJ, fewer heads perform more efficient work for a more economical price.
  • Save 57%
    $0.99
    $0.43
    Hunter

    Hunter - 538700 - Nozzle Rack for PGJ Series

    In Stock (4)

    Hunter 538700 - Nozzle Rack for PGJ Series Red nozzle rack Replaces original factory installed nozzles Numbers on nozzles represent flow rates Th...

    View full details
    $0.99
    $0.43
    Save 57%
    In Stock (4)
PGJ MODELS
PGJ-00 - Shrub
PGJ-04 - 4" Pop-up (10 cm)
PGJ-06 - 6" Pop-up (15 cm)
PGJ-12 - 12" Pop-up (30 cm)

DIMENSIONS
Overall height:
PGJ-00 - 7" (18 cm)
PGJ-04 - 7-1/8" (18 cm)
PGJ-06 - 9-1/8" (23 cm)
PGJ-12 - 16-3/8" (41 cm)
1/2" female inlet NPT
Exposed diameter: 1-1/8" (3 cm)

OPERATING SPECIFICATIONS
Radius: 15' to 37' (4.6 to 11.3 m)
Flow rate: 0.64 to 5.3 GPM
Recommended pressure range: 30 to 50 PSI (2.1 to 3.4 bars; 206 to 344 kPa)
Operating pressure range: 20 to 100 PSI (1.4 to 6.9 bars; 137 to 689 kPa)
Precipitation rates: approximately 0.60" (16 mm) per hour at 40 PSI (2.8 bars; 275 kPa) for spacings from 16' to 37' (4.6 to 11.3 m)
Nozzle trajectory: approximately 14

FEATURES
Models: Shrub, 4", 6", 12"
Arc setting: 40 to 360 degrees
Nozzle choices: 8
Nozzle Range: .0.75 to 5.0
Standard factory installed nozzle: 2.0 only
Through-the-top arc adjustment
Quick check arc mechanism
Water lubricated gear-drive
2-year Warranty
Headed and slotted set screw
Reclaimed water ID
Drain check valve (Up to 7' of elevation)

Note: To ensure optimum nozzle performance, the rotor should be operated in the "Recommended pressure range." The sprinkler will work normally when used in the "Operating pressure range", but nozzle performance may be reduced.

OPTIONS AVAILABLE
Drain check valve (Pop-up models only) for up to 7' (2.1 m) elevation change
Reclaimed water cover
