NDS Mini Channel 45° Fabricated Elbow with Removable Grate

Brand: NDS
Save 25%
$70.55
$52.91
SKU 5300

Notify me when back in stock

The NDS Mini Channel 45° Fabricated Elbow with Removable Grate is a compact, durable fitting designed to create a 45-degree turn in NDS Mini Channel drainage systems. The elbow features a PVC body and a slotted, snap-in polypropylene (PP) grate treated with UV inhibitors for long-term outdoor performance. Its gray finish matches other Mini Channel components and it is available in alternate colors for matching hardscape designs.

  • Compact 45° elbow for NDS Mini Channel systems — eliminates mitering straight channels.
  • Materials: PVC body with polypropylene (PP) snap-in grate; UV-stabilized for outdoor use.
  • Dimensions: nominal 3-5/8 in. length by 1-3/8 in. opening; intended for light-duty hardscape drainage.
  • Removable grate snaps in for easy cleaning and maintenance; couplings required to connect.
  • Ideal for pools, patios, spas, walkways and other light-duty hardscapes.

Easy to install and compatible with the NDS Mini Channel profile series, this fabricated elbow simplifies layout and keeps water moving away from structures. For project specifications, consult NDS product literature and installation manuals to confirm layout and coupling requirements.

Reviews

Frequently Asked Questions

What are the elbow's exact dimensions and opening size?
Measures approximately 3-5/8 in. length with a 1-3/8 in. opening; designed for the NDS Mini Channel profile.
Will this elbow fit my existing NDS Mini Channel system?
Yes. It is made for the NDS Mini Channel profile series and connects using Mini Channel Couplings.
What materials are used and how do I clean the grate?
PVC body with a PP snap-in grate. Remove the grate to clear debris and rinse with water; use mild detergent for stubborn grime.
Can I use this elbow in pool or patio installations?
Yes. It is intended for light-duty hardscape drainage such as pools, patios, spas, walkways, and similar applications.
