Coiled green 14 AWG Paige Electric Maxi 2‑wire decoder cable showing HDPE outer jacket and two insulated conductors, ready for direct‑burial irrigation use.

Paige Electric Maxi 2-Wire Decoder Cable — 14 AWG, Green

Brand: Paige Electric
Sold out
$2,352.38
$1,764.29
SKU 14/2X2500GR

Notify me when back in stock

Paige Electric 14/2X2500GR Maxi 2‑wire decoder cable is engineered for irrigation control systems that require a rugged, direct‑burial connection between controllers and remote decoders or valves.

  • Tin‑coated soft‑annealed copper conductors for corrosion resistance and reliable signal transmission.
  • 14 AWG, 2‑conductor construction with PVC insulation rated for 75°C (Type UF/TWU).
  • Pressure‑extruded high‑density polyethylene (HDPE) jacket provides direct‑burial protection and sunlight resistance.
  • Surface print reads “PAIGE ELECTRIC P7072D”; inner conductors are rated 600V while the outer jacket shows 48V to prevent use as building wire.
  • Meets UL/ETL/CSA listings for irrigation control cable. Recommended splice: 3M DBR/Y‑6 for durable, moisture‑resistant joints.

This cable is ideal for Rain Bird Maxi and other 2‑wire irrigation systems where durable, moisture‑resistant wiring is essential. Refer to the product spec sheet for detailed electrical and mechanical dimensions, jacket thickness, recommended installation practices, and splicing guidance.

Reviews

Frequently Asked Questions

What materials compose this 2‑wire decoder cable?
Tin‑coated soft‑annealed copper conductors with PVC insulation and an HDPE direct‑burial jacket for corrosion resistance.
Is this cable suitable for direct burial irrigation installations?
Yes. The HDPE jacket and PVC insulation are designed for direct‑burial use and the conductors are listed as Type UF by UL/ETL/CSA.
What splice method is recommended for field joints?
Paige recommends using 3M DBR/Y‑6 crimp/seal connectors to protect joints from moisture and corrosion.
