Rain Bird XF Series Dripline

The most flexible, pressure-compensating inline emitter tubing available to irrigate ground cover, dense plantings, hedge rows and more.
Extra flexible tubing for fast, easy installation. Dual-layered tubing (brown over black or purple over black) provides unmatched resistance to chemicals, UV damage and algae growth. Patent pending emitter design provides for increased reliability. Longer lateral runs than competition.
Operating Range
Pressure: 8.5 to 60 psi (0.7 to 4.1 bar)
Flow rates: 0.6 gph and 0.9 gph (2.3 l/h and 3.5 l/h)
Temperature: Up to 100°F (43°C) water; up to 125°F (51.7°C) ambient
Required filtration: 120 mesh

Outside diameter: 0.634" (16.1 mm)
Inside diameter: 0.536" (13.6 mm)
Wall thickness: 0.049" (1.2 mm)
Spacing: 12", 18" or 24"
Lengths: 100', 250', and 500' coils
