Rain Bird PRF075RBY 3/4-inch pressure-regulating filter shown on white background with cap and 200-mesh stainless steel screen visible.

Rain Bird PRF075RBY 3/4" Pressure-Regulating Filter (30 psi)

Brand: Rain Bird
Save 27%
$57.40
$41.62
SKU PRF075RBY
In Stock (36)

Notify me when back in stock

Compact combination unit that combines filtration and pressure regulation in one piece to protect downstream components in low-volume irrigation systems. Ideal for control zones where space, reliability, and simple maintenance matter.

  • Regulates outlet pressure to a nominal 30 psi (2.0 bar) for consistent emitter performance.
  • Pre-assembled 200-mesh (75 micron) stainless steel screen reduces debris and is easy to clean.
  • Glass-filled polypropylene body and cap provide a 150 psi (10.3 bar) maximum working rating for durable operation.
  • PF RBY cap includes a sealing O-ring and unthreads for quick, no-tools access to the filter element.
  • Fits 3/4" connections and supports low-flow ranges (0.2 to 5.0 gpm), ideal for drip and xerigation zones.
  • Designed to work seamlessly with valves to reduce parts, connections, and possible leak points in a control zone.

Comes with a replaceable stainless steel screen (RBY-200SSMX). Dimensions are approximately 6" L x 2" W x 4.5" H. Install the filter downstream of a control valve and avoid locating it under constant pressure. For routine cleaning, unthread the cap, remove the element, rinse debris, and reassemble using the O-ring seal. This compact Rain Bird unit simplifies installation and lowers long-term maintenance for residential and commercial low-volume irrigation systems.

Reviews

Frequently Asked Questions

What pressure does this PRF075RBY regulate to?
This unit regulates outlet pressure to a nominal 30 psi (2.0 bar) to stabilize emitter performance.
What filter size and replacement screen does it use?
The 3/4" model ships with a 200-mesh (75 micron) stainless steel screen; replacement RBY-200SSMX is available.
Where should I install the pressure-regulating filter?
Install downstream of the control valve and avoid constant pressure. If emitters are over 5 ft above, use a check valve.
