Front view of Irritrol RS500 wired rain sensor mounted on a gutter bracket, showing white UV-resistant 25 ft cable and bracket.

Irritrol RS500 Wired Rain Sensor with 25 ft UV-Resistant Cable

Brand: Irritrol
Save 27%
$54.71
$39.67
SKU RS500

Notify me when back in stock

The Irritrol RS500 Wired Rain Sensor stops scheduled irrigation when rainfall is detected, helping conserve water and protect landscapes. Its compact, durable housing and simple two-wire connection make installation quick. The sensor's reliable mechanical design minimizes false triggers and requires little maintenance once mounted.

  • Industry-standard hygroscopic discs detect rainfall and trigger the controller to halt watering.
  • Adjustable rainfall sensitivity (3–25 mm / 1/8–3/4 in) lets you set the activation threshold for your site.
  • Vent ring dry-out adjustment controls how long irrigation stays suspended after rain, from quick reset to extended delay.
  • Includes 25 ft (7.5 m) UV-resistant white-jacketed cable; cable can be extended up to 100 ft using 18 AWG outdoor-rated wire for flexible placement.
  • Works with normally open or normally closed sensor circuits and is compatible with most AC-powered controllers and timers.
  • UV-resistant engineered polymer housing with gutter clip, surface-mount screws, and conduit adapter for multiple mounting options; UL-listed for dependable outdoor service.

Documents: Sell Sheet and User Guide are available for download. Mount the RS500 clear of sprinkler spray with similar sun exposure as the landscape. Periodically clean the discs and check wiring; follow the included manual for wiring and configuration. Irritrol provides a multi-year limited warranty—refer to product literature for details.

Reviews

Frequently Asked Questions

What controllers is the RS500 compatible with?
Designed to work with most AC-powered irrigation controllers; supports normally open or normally closed sensor circuits.
How do I adjust the rain sensitivity and dry-out delay?
Use the Rainfall Adjustment Cap for threshold (3–25 mm / 1/8–3/4 in) and the vent ring to set the dry-out/reset rate.
Can I extend the RS500 cable if needed?
Yes. The supplied 25 ft cable can be extended up to 100 ft using 18 AWG outdoor-rated wire; seal and secure all connections.
