Close-up front view of Rain Bird 5004FC 4-inch pop-up rotor head showing full-circle nozzle, riser top, and visible adjustment features for installation.

Rain Bird 5004FC 4-inch Pop-Up Rotor - 360° Full Circle

Brand: Rain Bird
Save 44%
$27.38
$15.40
SKU 5004FC
In Stock (107)

Notify me when back in stock

The Rain Bird 5004FC is a 4-inch pop-up rotor engineered to deliver even, reliable full-circle irrigation for medium to large lawns and commercial sites. It combines Rain Curtain™ nozzle technology with a durable gear-drive design to maintain uniform distribution and resist wind drift.

  • Full-circle coverage: 360° arc with Rain Curtain nozzles for superior distribution and reduced misting.
  • Adjustable radius: Coverage radius 25–50 ft; radius can be reduced up to 25% using the radius reduction screw.
  • Rugged construction: Heavy-duty cover, slip-clutch adjustment, reinforced flow path, and added O-rings for debris protection.
  • Specifications: Pop-up height 4 in; overall height 7 3/8 in; exposed diameter 1 5/8 in; inlet 3/4" female NPT; no check valve.
  • Performance: Operating pressure 25–65 psi; flow range approximately 0.73–9.63 gpm depending on nozzle selection.
  • Contractor-friendly: Top-adjust arc and radius screws for quick field changes and simple installation on standard risers.

For complete nozzle charts, installation details, and maintenance instructions, consult the Rain Bird technical sheets and manuals supplied with the 5000 series rotors.

Reviews

Frequently Asked Questions

What pressure range does the Rain Bird 5004FC require?
Recommended operating pressure is 25–65 psi. Within this range the rotor maintains its specified radius and precipitation rates.
How large an area will one 5004FC cover?
The 5004FC provides 360° full-circle coverage with a radius of approximately 25–50 ft; radius can be reduced up to 25%.
Does the 5004FC include a built-in check valve?
No — the standard 5004FC has no built-in check valve. Consider 5000 Plus models or external check valves for pressure or anti-siphon needs.
