Front view of the Irritrol TC-24MOD-R 24-station replacement module showing the molded housing, label and station terminal strip.

Irritrol Total Control TC-24MOD-R - 24-Station Replacement Module

Brand: Irritrol
Save 24%
$1,034.03
$788.45
SKU TC-24MOD-R
In Stock (1)

Notify me when back in stock

The Irritrol TC-24MOD-R is a 24‑station replacement module engineered for the Total Control®-R controller family. It restores or expands station capability with a factory-compatible module that keeps programming and station wiring intact while supporting modern weather-sensing and remote options.

  • Factory replacement 24-station module for Irritrol Total Control-R systems, designed as a direct-fit station assembly.
  • Programmable: supports four independent programs, up to 16 start times and a full 365-day calendar to enable odd/even and interval scheduling.
  • Weather and remote ready: compatible with Irritrol Climate Logic® wireless weather sensing and SMRT Logic™ mobile gateway for automated schedule adjustments and remote access.
  • Accessory support: works with CL-100 wireless sensor, SMRT gateway, R-100 remote kit, R102-5476 adapter cable and standard pump start relays where applicable.
  • Indoor module dimensions: 7½" H x 9½" W x 4¼" D; sized to fit Total Control-R indoor housings and module bays.
  • Durable factory-fit assembly preserves common terminal connections and station wiring to simplify replacement and minimize downtime.

For installation, wiring diagrams and programming instructions, refer to the included sell sheet and user guides or the official Irritrol documentation. Always power down the controller before servicing; consult a licensed irrigation professional if you are unsure about electrical or wiring tasks.

Reviews

Frequently Asked Questions

What controllers is this module compatible with?
The TC-24MOD-R is a replacement module for the Irritrol Total Control-R series and fits Total Control-R indoor module bays.
How do I install the TC-24MOD-R replacement module?
Power down the controller, remove the old module per the user guide, seat the TC-24MOD-R in the module bay and reconnect station and common wiring as labeled.
What are the module dimensions and mounting type?
Indoor module dimensions are 7½" H x 9½" W x 4¼" D; it is a factory-fit module intended for Total Control-R indoor housings.
Can the module work with weather sensing or remote control?
Yes. The Total Control-R modules are compatible with Irritrol Climate Logic weather sensors and SMRT Logic mobile gateway for automated adjustments and remote access.
