Hunter PGV Valves

A complete line-up of rugged, professional-grade valves to handle the full range of landscapes.
Hunter PGV valves are hard-working, heavy-duty performers that offer you the best features for large and small landscapes:
For smaller landscape applications, the PGV is available in four 1" body configurations, in either an angle, globe, male x male, or male x barb design. In turn, each model is available as either flow control or non-flow control versions for whatever your needs may be.
For larger landscape applications, the PGV comes in both 1 1/2" and 2" globe/angle models (with flow control). All models feature durable high-grade construction and a rugged diaphragm with a support to prevent stress failure.
  • Save 34%
    $19.77
    $13.10
    Hunter

    Hunter - 606800 - Replacement 24V Solenoid

    In Stock (161)

    Hunter - 606800 - Replacement 24V Solenoid Fits ALL Hunter Valves Replacement Solenoid

    $19.77
    $13.10
    Save 34%
    In Stock (161)
  • Save 25%
    $40.93
    $30.70
    Hunter

    Hunter - 458200 - DC Latching Solenoid for all Valves

    In Stock (154)

    For all Hunter Plastic Valves Battery-Operated Controllers: SVC, WVS, & NODE Use INSTEAD of AC

    $40.93
    $30.70
    Save 25%
    In Stock (154)
  • Save 25%
    $26.67
    $20.00
    QCSC

    Service Buddy -Simple Valve Flushing

    In Stock (18)

    Simple Valve Flushing Easy to install  Compatible with Hunters 1 in PGV and Rain Birds 1 in DV Valves Requires your choice of  1/2" tubing – funny...

    View full details
    $26.67
    $20.00
    Save 25%
    In Stock (18)
  • Save 25%
    from $28.62
    from $21.47
    Hunter

    Hunter 1" PGV Valve | Select your Model

    In Stock (168)

    Flow: 0.2 to 40 GPM Recommended pressure range: 20 to 150 PSI Temperature rating: 150°F 24 VAC solenoid 350 mA inrush, 190 mA holding, 60 Hz 370 m...

    View full details
    from $28.62
    from $21.47
    Save 25%
    In Stock (168)
PGV MODELS
PGV-100G - 1" plastic globe valve, no flow control
PGV-101G - 1" plastic globe valve with flow control
PGV-100A - 1" plastic angle valve, no flow control
PGV-101A - 1" plastic angle valve with flow control
PGV-100MB - 1" plastic globe valve, no flow control, male thread x 1" barb
PGV-101MB - 1" plastic globe valve, with flow control, male thread x barb
PGV-100MB125 - 1" plastic globe valve, no flow control, male thread x 1 1/4" barb
PGV-101MB125 - 1" plastic globe valve, with flow control, male thread x 1 1/4" barb
PGV-100MM - 1" plastic globe valve, no flow control, male x male thread
PGV-101MM - 1" plastic globe valve, with flow control, male x male thread
PGV-151 - 1 1/2" plastic angle/globe valve with flow control
PGV-201 - 2" plastic angle/globe valve with flow control

DIMENSIONS
• 1" Globe and Male x Male: 5" H x 4 1/2" L x 2 1/2" W
(13 cm H x 11 cm L x 6 cm W)
• 1" Male x Barb: 5" H x 5 1/2" L x 2 1/2" W
(13 cm H x 14 cm L x 6 cm W)
• 1" Angle: 5 1/2" H x 3 1/2" L x 2 3/4" W
(14 cm H x 9 cm L x 7 cm W)
• 1 1/2" Globe/Angle: 7 1/2" H x 5 3/4" L x 4 1/2" W
(19 cm H x 15 cm L x 11 cm W)
• 2" Globe/Angle: 8" H x 6 3/4" L x 5 1/4" W
(20 cm H x 17 cm L x 13 cm W)

OPERATING SPECIFICATIONS
• Flow: .2 to 120 GPM (0.04 to 27.2 m3/hr; 0.7 to 454.2 l/min)
• Pressure: 20 to 150 PSI (1.4 to 10.3 bars; 138 to 1034 kPa)
• Ambient temperature: up to 150°F (66°C)
• Heavy-duty solenoid: 24VAC, 370mA inrush current,
190mA holding current, 60 cycles; 475mA inrush current,
230mA holding current, 50 cycles

OPTIONS AVAILABLE
• Accu-Set™ pressure regulator
• Reclaimed water identification handle PGV-101 models (part # 269205)
for PGV-151/201 models (part# 412705)
• DC latching solenoid (part # 458200)
• Solenoid conduit cover (part # 464322)
